Field Sprayer Heavy Type MHA

  • Tractor mounted sprayers by PTO via shaft developed to meet the different requirements of plant protection treatments. Sprayers extremely versatile and suitable, according to the applications, to operate in open-field cultivations, sprayer and distribute herbicides among the plant rows the availability of several mechanical and hydraulic spraying booms together with different equipments and option allow our sprayers to suit the requirement of the single users in the specific treatments.
  • Easily mountable on 3-pt of tractors
  • Level indicator on the tank
  • Polythene tanks
  • Easily cleanable water filter
  • Booms are removable for loading and transportation
  • High efficiency
  • Clean water tank
  • Pressure regulation
Field Sprayer Heavy Type  MHA
Field Sprayer Heavy Type  MHA
Type MHA 800 MHA 1000 MHA 1200
Pump Model (I/min) C96 C96 C96
Control Panel VDR 50 VDR 50 VDR 50
Boom Length (m) 16 16 16
Noozle Type Brass-Plastic Brass-Plastic Brass-Plastic
Noozle Piece 30 30 30
Width (cm) 80 80 80
Lenght (cm) 158 158 165
Height (cm) 186 188 188
Bum Height (CM) Hydraulic Hydraulic Hydraulic
Required Power (BG) 50 50 50
Working Transfer  540 540 540
Weight (kg) 480 540 560
