Reversible Plough CRP

  • The Implements of trailed and mounting types of disc harrows are mounted to the tractors by three point linkages. Additionaly, the user can also use it as trailed type. Disc harrows are made of steel square rods arranged in row with bearings.
  • High resistant, heat treated disc set frames are connected main frame. Used for scrapping pieces on the soil and stems of sunflower, wheat, rice, plant remnants wild grass.
  • And also to break the surface of the soil and mix the manure and chemical fertilizers with the soil.
  • Disc harrows are used either in cultivating vineyard, garden, fruit tree and olive tree fields or in cultivating plain fields.
  • Preferably used type in the fields of trees and vineyards is mounted type and in the plain fields, the trailed type is preferred.
Reversible Plough CRP
Reversible Plough CRP
  Units CRP2 CRP3 CRP4 CRP5 CRP6
Number of Bodies pcs 2 3 4 5 6
Total Length cm 193 284 378 450 600
Total Width cm 170 204 238 285 320
Total Height cm 158 158 158 164 164
Working Depth cm 35 35 35 35 35
Working Width cm 62-90 93-135 120-180 155-225 180-252
Space of Body cm 85 80 80 85 80
Body Size inch 14 14 14 14 14
Chassis Size mm 140X120 140X120 140X120 160X120 160X140
Tractor Power hp 60-65 80-85 90-120 130-60 170-195
Total Weight kg 550 890 1065 1305 1540
